The NTE0303MC is a part of NTE series DC/DC power supply. It has an operating temperature ranging from -40°C to +85°C and is available in DIP-8 package.
Features:
Lead frame technology
Single isolated output
1 kVDC Isolation
Effi ciency up to 78%
Power density 1.8W/cm3
Wide temperature performance at full 1 Watt load, –40°C to 85°C
UL 94V-0 Package material
Footprint over pins 1.37cm2
3.3 V, 5 V & 12 V Input
3.3 V, 5 V, 9 V, 12 V & 15 V output
No heatsink required
Internal SMD construction
Toroidal magnetics
MTTF up to 6.8 million hours
Custom solutions available
Multi-layer ceramic capacitors
Категория:
DC/DC преобразователи
Артикул:
9010230
Наличие:
754
-
Mounting Method:
Surface Mount
-
ECCN:
EAR99
-
Информация PCN:
N/A
-
Статус части:
Active
-
Размер минимального заказа, шт.:
35
-
Производитель:
Murata Power Solutions
-
Тикер производителя:
MPS
-
Модель модификации:
NTE0303MC
-
Модель:
tube
-
Артикул (SKU):
9010230
-
Ссылка на предложение поставщика:
https://www.futureelectronics.com/p/electromechanical--power-supplies--dc-dc/nte0303mc-murata-power-solutions-9010230
-
Operating Temp Range:
-40°C to +85°C
-
Type:
Encapsulated
-
Dimension:
L 15.2mm x W 7.6mm x H 6.6mm
-
Power Dissipation:
1W
-
Output Power:
1W
-
No of Outputs:
Single
-
Output Voltage:
3.3V
-
Switching Frequency-Max:
110kHz
-
Isolation:
Isolated
-
Input Voltage:
3.3V
-
Efficiency:
73%
-
Load Regulation (%):
14%
-
Output Current:
0.03A
-
Ripple & Noise:
40mV
-
Скачать Datasheet kdc-nte.pdf:
https://www.murata.com/products/productdata/8807031767070/kdc-nte.pdf?1583754813000
