The MMBD301L series of Silicon Hot-Carrier Diodes are designed primarily for high-efficiency UHF and VHF detector applications. They are readily adaptable to many other fast switching RF and digital applications. They are supplied in an inexpensive plastic package for low-cost, high-volume consumer and industrial/commercial requirements. They are also available in a Surface Mount package.
Key Features:
Extremely Low Minority Carrier Lifetime - 15 ps (Typ)
Very Low Capacitance - 1.5 pF (Max) @ VR = 15 V
Low Reverse Leakage - IR = 13 nAdc (Typ)
These Devices are Pb-Free, Halogen Free/BFR Free and are RoHS Compliant
Note:
Moisture Sensitivity level (MSL) for surface mount devices (lead free measured at 260°C reflow, non lead free at 235°C reflow)
Категория:
Диоды Шоттки
Артикул:
7916786
Наличие:
365
-
Package Style:
SOD-323
-
Mounting Method:
Surface Mount
-
ECCN:
EAR99
-
Информация PCN:
N/A
-
Статус части:
Active
-
Размер минимального заказа, шт.:
30000
-
Производитель:
Onsemi
-
Тикер производителя:
ON
-
Модель модификации:
MMDL301T1G
-
Модель:
reel
-
Артикул (SKU):
7916786
-
Ссылка на предложение поставщика:
https://www.futureelectronics.com/p/semiconductors--discretes--diodes--schottky-diodes/mmdl301t1g-onsemi-7916786
-
Forward Voltage:
0.52V
-
Reverse Current-Max:
200nA
-
Reverse Voltage-Max [Vrrm]:
30V
-
Power Dissipation:
200mW
-
Скачать Datasheet MMDL301T1-D.PDF:
http://www.onsemi.com/pub_link/Collateral/MMDL301T1-D.PDF
