The 25.346.3553.0 is a Part of 8213 Series PCB female connector, pitch 5,08 mm, wire lead opposite to the coding and 90° to the connecting direction, screw connection, 36 5-pole, colour grey, without marking Style Terminal Block.
Features:
Modular spacing5.08 mm
Connection type: Screw connection
Number of poles: 5
Mating direction towards connector: 90°
Nominal cross section: 2.5 mm²
Rated current 12 A
Overvoltage Category I: 1000 V
Overvoltage Category II: 400 V
vervoltage Category III: 250 V
Rated impulse voltage4 kV
Cross section: UL22-12 AWG
Voltage UL: 300
Current field wiring: 15 A
View the Available PCB Connectors
View the Available PCB Connectors
Категория:
Гребенки
Артикул:
5217781
Наличие:
642
-
ECCN:
EAR99
-
Информация PCN:
N/A
-
Статус части:
Active
-
Размер минимального заказа, шт.:
50
-
Производитель:
Wieland Electric
-
Тикер производителя:
WIE
-
Модель модификации:
25.346.3553.0
-
Модель:
box
-
Артикул (SKU):
5217781
-
Ссылка на предложение поставщика:
https://www.futureelectronics.com/p/interconnect--pin-and-socket-connectors--header-plug-board-mount/25-346-3553-0-wieland-electric-5217781
-
No of Positions:
5
-
Style/Orientation:
Vertical Header/Plug
-
Pitch:
5.08 mm
-
Скачать Datasheet 25.346.3553.0.pdf:
http://www1.futureelectronics.com/doc/Wieland Electric/25.346.3553.0.pdf
